Products
Side-entry IML robots, IML equipment, quality control and downstream automation. Datasheets for SE robots; specifications, option list and comparison for every model.
SE · Side-entry IML robots
80–700 t machines, 1–16 cavities; SE-Twin for stack moulds
NewSE-CompactSE-Compact Side-Entry IML Robot
Entry-level IML for small containers and lids: 1–4 cavities on 80–160 t machines.
- 2.6sDry cycle
- 1.0sIntervention
- 1–4Cavities
SE-250SE-250 Side-Entry IML Robot
The standard for yoghurt and margarine tubs: 2–8 cavities on 150–300 t machines, 2.4 s dry cycle.
- 2.4sDry cycle
- 0.9sIntervention
- 2–8Cavities
SE-450SE-450 Side-Entry IML Robot
The workhorse of high-cavity lines: 4–16 cavities on 300–500 t machines, 2.2 s dry cycle, double stacking.
- 2.2sDry cycle
- 0.8sIntervention
- 4–16Cavities
SE-650SE-650 Side-Entry IML Robot
For pails and large containers: 2–16 cavities on 450–700 t machines, 30 kg payload, handle assembly integration.
- 3.0sDry cycle
- 1.1sIntervention
- 2–16Cavities
NewSE-TwinSE-Twin Stack-Mould IML Robot
For stack moulds: 2×6 and 2×8 cavities, double-sided plate, both mould faces in a single entry.
- 2.6sDry cycle
- 1.0sIntervention
- 2×6 / 2×8Cavities
LM · Label magazines
4- and 8-station servo magazines
LM-4LM-4 Label Magazine
Four-station servo label magazine: 600 labels per cassette, cassette change in 90 seconds.
- 4Stations
- 600labels/cassetteCapacity
- 1–4Cavities
LM-8LM-8 Label Magazine
Eight-station magazine: 800 labels per cassette, two units side by side for 16 cavities.
- 8Stations
- 800labels/cassetteCapacity
- 4–16Cavities
ES/VG/DM · Static charging, EOAT and mandrels
Electrostatic charging unit, product-specific EOAT plate and mandrel sets
ES-ChargeES-Charge Electrostatic Charging Unit
Simco-Ion based charging unit: the label holds to the mould wall, vacuum stays only for transfer.
- 0–30kVCharging
- <0.3sCharging time
VG-EOATVG-EOAT Vacuum Head
Product-specific double-sided EOAT plate: label cores, vacuum grippers, 3D-printed mandrels.
- 1–16Cavities
- 4–14kgPlate weight
DM-SetDM-Set Dummy and Mandrel Set
Label-carrying cores and trial dummies: trial set in 5 working days, series set in 2–3 weeks.
- 1–16Cavities
- 5working daysTrial set
- 2–3weeksSeries set
VQ · Vision inspection
Camera-based label inspection
DS/HA/TK · Downstream automation
Conveyor, stacking, handle assembly, turnkey line
DS-StackDS-Stack Stacking Unit
Counts, stacks and groups mouth-down containers to the packing quantity; 1–2 stacking lanes, 4 as an option.
- 1–2Stacking lanes
- ≤ 300pcs/minStacking rate
DS-ConveyorDS-Conveyor Outfeed Conveyor
PU or modular-belt outfeed conveyor: food-grade, servo speed, synchronised with the robot.
- 1.5–6mLength
- ≤ 40m/minSpeed
HA-HandleHA-Handle Handle Assembly Unit
Fits the handle to the pail in-line in 4 seconds; plastic and metal handles, 2–20 L.
- 15Handles/min
- 1–2Cavities
TK-LineTK-Line Turnkey IML Line
Robot + magazine + vision + stacking + boxing: one contact, one HMI, one acceptance test.
- 1–4Cells
- 2–16Cavities
- 150–700tIMM tonnage
TO · Take-out robots
Side-entry take-out for unlabelled lids and cups
Let's find the right robot for you
Choose your container and machine, and our models are ranked by how well they fit.
Best-matching robots
- SE-250SE-250 Side-Entry IML Robot100% match
- Tonnage fits
- Cavities fit
- Meets the cycle target
- SE-450SE-450 Side-Entry IML Robot49% match
- Tonnage fits
- Cavities fit
- Meets the cycle target
- SE-650SE-650 Side-Entry IML Robot49% match
- Tonnage fits
- Cavities fit
- Meets the cycle target
Compare the SE series
| Feature | SE-250 | SE-450 | SE-650 |
|---|---|---|---|
| Suitable IMM clamping force | 150–300 t | 300–500 t | 450–700 t |
| Number of cavities | 2–8 pcs | 4–16 pcs | 2–16 pcs |
| Dry cycle time | 2.4 s | 2.2 s | 3.0 s |
| Mould intervention time | 0.9 s | 0.8 s | 1.1 s |
| Payload | 12 kg | 18 kg | 30 kg |
| X-axis stroke (entry) | 1,200 mm | 1,600 mm | 2,000 mm |
| Magazine stations | 4; 8 with the LM-8 option | 8; 2×8 for 16 cavities | One per cavity (2–16) |
| Lead time | 8–10 weeks | 8–10 weeks | 10–12 weeks |
| View details → | View details → | View details → |
Four technologies, one cell
- 010.8s
Servo main axis
Rack + linear guide, up to 5.5 m/s; mould intervention from 0.8 s on IML robots.
- 0216cavities
Multi-cavity magazine
Servo drive and level sensor per cassette; up to 16 cavities.
- 0330kV
Electrostatic charging
Simco-Ion Chargemaster, two channels, material-based profiles.
- 0420ms
Vision inspection
Dual camera, 20 ms decision, ±0.3 mm position; per-cavity statistics.
How much will your line produce?
Enter cavities and cycle time to see parts per hour, month and year. Carry the result to the quote form in one click.
Between 1 and 128
Between 0.5 and 120
Between 1 and 24
Between 1 and 365
Between 50 and 100
- Per hour
- 2,448parts
- Per day
- 53,856parts
- Per month
- 1,346,400parts
- Per year
- 16,156,800parts
Formula: cavities × 3600 ÷ cycle time × efficiency = parts per hour; monthly = yearly ÷ 12.
Estimate only; mould changes, downtime and scrap are covered by the efficiency rate.
Get a quote for this capacityFrequently asked questions about products
Injection moulding machines we work with
We connect to any machine with a Euromap 67 interface. Tonnage and mould daylight are checked at quotation stage.
Describe your application; we get back within 48 hours with a preliminary quote and application analysis.
Your container, label and mould details are enough. You can also run a trial with your own mould at the İkitelli test centre.
